W-Modbus wall mount
SKU 840-2110
- Modbus RTU through reliable wireless mesh
W-Modbus eliminates the need to run control cables for Modbus RTU installations significantly reducing time-consuming cable installations, installation planning, troubleshooting, and daisy-chaining.
With LumenRadio’s technology it is possible to create a wireless Modbus RTU network that maintains the standardization of the protocol and by converting the Modbus signals into LumenRadio’s Mira technology we can send the Modbus RTU signal wirelessly with low latency. We call this W-Modbus.
The W-Modbus product is built upon LumenRadio’s MiraOS and MiraMesh, consisting of several patented features enabling extremely reliable radio communication, fast installation, and extended range. MiraOS is used in a vast number of installations around the world for building automation, HVAC control, lighting control and industrial sensor networks.
A W-Modbus unit can be configured either as a Gateway that is connected to the Modbus Client, or a Node that is connected to the Modbus Server. A W-Modbus network can consist of up to 100 Nodes.
W-Modbus utilizes the international license free ISM band at 2.4GHz.
Replacing wires with wireless communication brings significant benefits without changing the existing ecosystem. Legacy wired devices such as sensors, can be converted into wireless devices, providing increased flexibility and cost savings, both during installation and steady-state operation.
INSTANT INSTALLATION
UNIQUE RELIABILITY
BAUD RATE AGNOSTIC
LONG RANGE
- W-Modbus Product sheet_English
- W-Modbus Product sheet_German
- W-Modbus Installation guide_PDF
- W-Modbus Installation guide_Video
- W-Modbus Solar installations product sheet_PDF_English
- W-Modbus Solar installations product sheet PDF_German
- W-Modbus Solar installation guide PDF_English
- W-Modbus Solar installation guide_Video
- Wireless in Building Automation
- Wireless in Building Automation_German
- W-Modbus Quick Start Guide
- Out-of-the-box installation – just power up and connect to your Modbus device and you are up-and-running.
- Instant commissioning – 3 simple steps, commissioning the W-Modbus network in minutes.
- Mesh network – cover an entire building, utilizing the mesh network as your infrastructure.
- Range – 500 meters (line-of-sight) per hop in the mesh network.
- Cognitive Coexistence – LumenRadio’s patented technology provides industrial-grade reliability and immunity to interference.
- Self-optimizing network – the mesh network will always find the best way to send messages through the network between devices.
- Modular configuration – you no longer need to have the same baud rate in the whole network, supports individual settings for each device.
- Power supply: 24 VAC ±15% 50-60 Hz, 24 VDC ±15%
- Max. power consumption: 2.5 W
- 24 V output max. power: 10 W
- Auto resettable fuse: Yes
- Cable rating, connector: solid / stranded 0.14 – 0.5 mm2 / 0.2 – 0.5 mm2 conductor sizes (AWG) 24 – 20
- Frequency band: 2.45 GHz, ISM band (2400-2483 MHz)
- Baud rate: 9600, 19200, 38400, 76800 bps
- Stop bit: 1, 2
- Parity: none, even
- Number of Servers: 100 Servers to one Client
- Number of hops: 8 hops in the meshing network
- Range per hop: 500 m line of sight (approximately 50- 70 m indoors with walls)
- Output (ERP): Max 20 dBm
- IP class: 40
- Material: ABS UL94-V0
- Colour: White, RAL 9003
- Ambient temperature: Operating: -20 to +55°C Storage: -30 to +80°C
- RH: 10 – 95% non-condensing
- Weight: 95g
- Dimensions: W86.0 x H86.0 x D25.5 mm
A W-Modbus network consists of a single W-Modbus Gateway connected to the Modbus Client using a Modbus RTU cable and up to 100 W-Modbus Nodes, each of them connected to one Modbus Server over a Modbus RTU cable.
The device is an “end device with internal terminal resistors”. Can this termination be switch off?
No it can not. Typical usage of the product is that the product is end of line.
Can I install multiple Modbus RTU Clients (masters) at the same place?
Yes, as long as you install one network at a time each network gets their own network key.
Can I connect several Modbus RTU Servers (slaves) behind one W-Modbus unit?
This is possible on the W-Modbus Wall mount PRO unit.
How many Modbus RTU Servers (slaves) can I have in one network?
It is possible to have 100 Servers (slaves) connected to one Client (master).
How do I give the W-Modbus Node its Modbus ID?
The W-Modbus unit do not need any Modbus ID. It will proxy it's Modbus server (slave) ID. The third LED (bottom on Wall mount and right on DIN rail) will flash green every five seconds if the W-Modbus node fins an modbus id on the bus with a correct baud rate. It will flash red otherwise.
Does W-Modbus transfer Modbus signals wirelessly?
The W-Modbus units transfer Modbus RTU signals and not Modbus TCP.
Is the communication in the network encrypted?
Yes, all communication in the W-Modbus Network is encrypted with AES128.
On-Demand Webinar
Find your Superpower with wireless building automation.
No cables – No problems
W-Modbus replaces the Modbus RTU cable with a reliable wireless mesh. No need for construction work in retrofit or greenfield installations.
W-Modbus eliminates time-consuming installation planning, cabling, daisy-chaining and trouble-shooting. Avoiding cabling has never been easier.
