W-Modbus Compact
SKU 840-2130
Small footprint for fast installation on or inside the wall.
– Click on mount
– No dip switches
– Screw terminals
For hotels, offices, retails etc. Room controllers, VAVs, FCUs etc.
Modbus RTU through reliable wireless mesh
W-Modbus replaces the Modbus RTU cable with a reliable wireless mesh – it eliminates time-consuming installation planning, cabling, daisy-chaining and trouble-shooting. Plug-n-Play: No programming required. Enable energy savings and meet sustainability targets with wireless control.
The W-Modbus product acts as a proxy for a connected Modbus RTU device, effectively extending the bus and creating the possibility to make wired products wireless. A W-Modbus network consists of a single W-Modbus gateway with up to 100 W-Modbus Nodes.
Patented technologies
The W-Modbus product is built upon LumenRadio’s patented meshing technology MiraMesh - providing ultra-reliable device-to-device connectivity, easy installation, concurrent Bluetooth and extended range.
With LumenRadio’s W-Modbus solution it is possible to create a wireless Modbus RTU system that maintains the Modbus RTU standard, while still keeping a low latency.
INSTANT INSTALLATION
UNIQUE RELIABILITY
ECO-DESIGNED
LONG RANGE
- Out-of-the-box installation – just power up and connect to your Modbus device and you are up-and-running.
- Instant commissioning – 3 simple steps, commissioning the W-Modbus network in minutes.
- Mesh network – cover an entire building, utilizing the mesh network as your infrastructure.
- Range – 500 meters (line-of-sight) per hop in the mesh network.
- Cognitive Coexistence – LumenRadio’s patented technology provides industrial-grade reliability and immunity to interference.
- Self-optimizing network – the mesh network will always find the best way to send messages through the network between devices.
- Modular configuration – you no longer need to have the same baud rate in the whole network, supports individual settings for each device.
POWER
- Voltage range AC: 24VAC ±10%
- Voltage range DC: 12-24VDC ±10%
- Max power consumption: 2.5W
- Conductor cross section (stranded): 0.2 – 1.5mm2
- Conductor cross section (solid): 0.2 – 1.5mm2
- AWG: 24 – 16
- 24V throughput power: N/A
- Power source restriction:Only to be powered by a UL-listed LPS power supply of max 15W
ENVIRONMENT
- Ambient operating temperature: -20 to +55°C
- Ambient storage temperature: -30 to +80°C
- Relative humidity: 10 – 95% non-condensing
MECHANICAL
- Dimensions in mm (WxHxD): 48x85x22
- Weight: 55g
- Protection level: IP40
A W-Modbus network consists of a single W-Modbus Gateway connected to the Modbus Client using a Modbus RTU cable and up to 100 W-Modbus Nodes, each of them connected to one Modbus Server over a Modbus RTU cable.
On-Demand Webinar
Find your Superpower with wireless building automation.
No cables – No problems
W-Modbus replaces the Modbus RTU cable with a reliable wireless mesh. No need for construction work in retrofit or greenfield installations.
W-Modbus eliminates time-consuming installation planning, cabling, daisy-chaining and trouble-shooting. Avoiding cabling has never been easier.
